The H3C MS4100V2-EI series security switches are widely used in security scenarios such as hotels, restaurants, enterprises and campuses.

Brand Name:	H3C
Model Number:	MS41000V2 Series
MOQ:	1
Price:	depending on order quantity and specific model
Payment Terms:	T/T
Supply Ability:	Up to 30 days

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Packaging Details:

See the hardware specification sheet for details based on the specific model

Supply Ability:

Up to 30 days

Highlight:

H3C MS4100V2-EI security switch

network switch for hotels campuses

enterprise security network switch

Product Description

Rich Port Types

The entire product line supports combined Ethernet ports + optical ports to meet networking demands of diverse scenarios and enable flexible deployment.
Available in 8‑port, 24‑port and 48‑port models. All ports provide Gigabit wire‑speed forwarding to satisfy differentiated user requirements.

Reliable Security Policies

Integrated with dedicated ARP intrusion detection to effectively defend against ARP spoofing attacks initiated by hackers via malicious ARP packets.
Supports IP Source Guard to prevent illegal address spoofing (MAC spoofing, IP spoofing, MAC/IP spoofing) and DoS attacks.
DHCP Snooping is supported to prohibit unauthorized private DHCP servers and ensure the authenticity and consistency of DHCP networking environments.
Comprehensive port security features defend against MAC‑based attacks and allow or restrict traffic based on MAC addresses.
Supports 802.1X and MAC authentication, client software version detection, Guest VLAN and other functions. When cooperating with the iMC platform, it realizes proxy detection and dual‑network adapter detection.

Enhanced Multi‑service Capabilities

Supports port rate limiting and traffic rate limiting to prevent malicious bandwidth occupation and deliver refined traffic management.
Provides three queue scheduling algorithms: SP (Strict Priority), WRR (Weighted Round Robin) and SP+WRR, ensuring multi‑priority data transmission.
Offers complete IPv6 service features and diversified IPv6 management tools.

User‑friendly Network Management

Supports CLI, Web management and Telnet for convenient device maintenance. Encrypted management modes such as SSH 2.0 ensure secure remote access.
Remote device upgrade via FTP/TFTP; compatible with SNMP v1/v2c/v3. It adapts to mainstream management platforms including the iMC Intelligent Management Center and OpenView.

Green & Energy‑saving Design

Optimized power‑saving design reduces overall power consumption and failure risks, while lowering radiation to household appliance levels for human health protection.
The whole device complies with the EU RoHS directive for eco‑friendly materials and safety standards.

Attribute	MS4100V2-10P-EI	MS4100V2-28P-EI	MS4100V2-52P-EI	MS4100V2-10P-HPWR-EI	MS4100V2-28P-HPWR-EI	MS4100V2-52P-PWR-EI
MS4100V2-EI Series Specifications
Switching Capacity	432Gbps	432Gbps	432Gbps	432Gbps	432Gbps	432Gbps
Packet Forwarding Rate	72Mpps	96Mpps	144Mpps	72Mpps	96Mpps	144Mpps
Management Port	1 × Console port	1 × Console port	1 × Console port	1 × Console port	1 × Console port	1 × Console port
Port Description	8 × 10/100/1000BASE-T ports,2 × 1000 BASE-X SFP ports	24 × 10/100/1000BASE-T ports,4 × 1000 BASE-X SFP ports	48 × 10/100/1000BASE-T ports,4 × 1000 BASE-X SFP ports	8 × 10/100/1000BASE-T ports,2 × 1000 BASE-X SFP ports	24 × 10/100/1000BASE-T ports,4 × 1000 BASE-X SFP ports	48 × 10/100/1000BASE-T ports,4 × 1000 BASE-X SFP ports
Electrical Port Features	Supports half-duplex, full-duplex and auto-negotiation modes	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Ethernet Features	LLDP, static MAC configuration,MAC address learning limit (max. 8K),port mirroring & traffic mirroring,port aggregation (max. 8 ports per group, up to 24 groups),port isolation, STP/RSTP/MSTP,IEEE 802.3ad & static link aggregation	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
VLAN	IEEE 802.1Q (max. 4K VLANs),MAC-based VLAN, Guest VLAN,VLAN mapping, MVRP	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
IP Routing	Static routing support	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
DHCP	DHCP Relay, DHCP Client, DHCP Snooping	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Multicast	IGMP V1/V2/V3 Snooping,PIM Snooping, Multicast VLAN	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
QoS	SP / WRR / SP+WRR queue scheduling,802.1p priority mapping, port rate limiting	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
ACL	L2/L3/L4 ACL, IPv4/IPv6 ACL, VLAN ACL	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
IPv6	IPv6 static routing, dual stack,DHCPv6 Client, DHCPv6 Snooping,ND and PMTU support	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Port Lightning Protection	10KV	10KV	10KV	10KV	10KV	10KV
Reliability	Ethernet OAM, DLDP, Monitor Link	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Security Features	Hierarchical user management & password protection,SSH encrypted login, restricted FTP access,defense against ARP/broadcast/multicast/TTL=1 packet attacks,MAC address restriction, IP+MAC+PORT binding,IEEE 802.1X, Radius & AAA, SNMPv3,broadcast packet suppression	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
System Management	Console/AUX Modem/Telnet/SSH CLI,FTP/TFTP/Xmodem/SFTP file management,SNMP v1/v2c/v3, SFlow, NQA, NTP,system operation log	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Operating Temperature	-10℃～50℃	-10℃～50℃	-10℃～50℃	-10℃～50℃	-10℃～50℃	-10℃～50℃
Humidity	Operating: 5%～95% (Non-condensing)Storage: 5%～95% (Non-condensing)	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Environmental Standard	China RoHS, EEE	China RoHS, EEE	China RoHS, EEE	China RoHS, EEE	China RoHS, EEE	China RoHS, EEE
PoE	Not supported	Not supported	Not supported	PoE+ supported,Max single-port output: 30W	PoE+ supported,Max single-port output: 30W	PoE+ supported,Max single-port output: 30W
Power Consumption	Min: 8WMax: 15W	Min: 9WMax: 23W	Min: 18WMax: 41W	Min: 14WMax: 156W (PoE: 125W)	Min: 19WMax: 448W (PoE: 370W)	Min: 36WMax: 467W (PoE: 370W)
Weight (Full Configuration)	≤1.5kg	≤2.5kg	≤3.5kg	≤3kg	≤6kg	≤6kg
Input Voltage	AC: Rated: 100V～240V AC, 50/60HzMax: 90V～264V AC, 47～63Hz	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left	Consistent with the left
Dimensions (L×W×H, mm)	264×162×44	440×160×44	440×230×44	330×230×44	440×260×44	440×400×44
