H3C S5136S‑48FP4S‑EI 48‑Port High‑Power PoE+ Gigabit Access Switch with GE SFP Uplink & IRF2 Stacking

Brand Name:	H3C
Model Number:	S5136S-48FP4S-EI
MOQ:	1
Price:	$746(According to the Model and configuration requirements)
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	500

Detail Information

Product Description

Detail Information

Place of Origin:

China

Document:

Model Number:

S5136S-48FP4S-EI

System Switching Capacity:

336Gbps

Forwarding Rate:

78Mpps

Product Type:

Campus Network Switches-Access Switch

Warranty:

3 Years

Port Switching Capacity:

104Gbps

Ports:

48*10/100/1000 Base-T Port

Communication Mode:

Full-Duplex & Half-Duplex

Dual Core, 1.2GHz

SFP Port:

Input Voltage:

Rated Voltage Range: 100 VAC To 240 VAC @ 50 Hz Or 60 Hz

Dimension:

44 × 440 × 260 Mm

Console Port:

Packaging Details:

Original packaging

Supply Ability:

Highlight:

H3C S5136S 48-port PoE+ switch

Gigabit access switch with SFP uplink

High-power PoE+ switch with IRF2 stacking

Product Description

H3C S5136S‑48FP4S‑EI 48‑Port High‑Power PoE+ Gigabit Access Switch with GE SFP Uplink & IRF2 Stacking

H3C S5136S-48FP4S-EI 48 Port Gigabit PoE+ Switch 770W L3 Managed 4 SFP Uplink for IP Camera Wireless AP VoIP Hotel Campus

Key Features

48‑port PoE+ with 770W high PoE budget, support AI‑PoE, Fast‑PoE and PoE watchdog self‑healing
Four GE SFP optical uplink ports for fiber uplink, ideal for mass IP‑camera and Wi‑Fi‑AP high‑density PoE access
IRF2 stacking supports up to 9 units as one logical device, single‑IP management with link redundancy
Full L3 routing including static route, RIP, OSPF for IPv4/IPv6 for large‑scale campus complex networking
Single‑port triple‑authentication, ARP defense and EAD access control for large‑scale LAN multi‑layer security
Type‑C Console plus independent OOB port, ZTP zero‑touch provisioning and Cloudnet remote O&M
10KV surge‑protected service ports, license‑free full features to reduce enterprise total ownership cost

Technical Specifications

Item	S5136S‑48FP4S‑EI
Port Layout	4810/100/1000BASE‑T PoE+, 41000BASE‑X SFP
Port Switching Capacity	104Gbps
Forwarding Rate	78Mpps
System Switching Capacity	336Gbps
CPU	Dual‑Core 1.2GHz
SDRAM / Flash	2GB / 1GB
Dimension (HWD)	44 * 440 * 260 mm
Full‑load Weight	≤4.2 kg
Total PoE Budget	770W
Cooling Mode	2 built‑in fans
Latency (64‑byte)	≤2.1μs
Management Interface	Console, Type‑C Console, 1*GE OOB, USB
Max Stacking Bandwidth	16Gbps
Input Voltage	AC 90‑264V
Operating Temperature	-5℃ ~ 50℃
Virtualization	IRF2 stacking, cross‑device link aggregation
Routing Protocol	Static route, RIP, OSPF IPv4/IPv6
Security Features	802.1X/Portal/MAC triple‑auth, ARP defense, EAD
O&M Capability	Cloudnet, SmartMC, ZTP zero‑touch provisioning
