The H3C MS4000 series security switches serve as an ideal bearing platform for building green, eco-friendly and energy-efficient monitoring and IoT networks.

All Category

Optical Modules

Mr. JIMI

jimi@mailian-it.com

+86 13212755002

Chat Now

The H3C MS4000 series security switches serve as an ideal bearing platform for building green, eco-friendly and energy-efficient monitoring and IoT networks.

Brand Name:	H3C
Model Number:	MS4000 Series
MOQ:	1
Price:	depending on order quantity and specific model
Payment Terms:	T/T
Supply Ability:	Up to 30 days

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Packaging Details:

See the hardware specification sheet for details based on the specific model

Supply Ability:

Up to 30 days

Highlight:

H3C MS4000 security switch

energy-efficient network switch

IoT monitoring network switch

Product Description

Product Features

Compliant with IEEE 802.3 10Base‑T, IEEE 802.3u 100Base‑TX, IEEE 802.3x and IEEE 802.3ab 1000Base‑T standards.
Wire‑speed Layer 2 gigabit forwarding on all ports. The MS4010 / MS4010‑HPWR is equipped with two gigabit uplink optical ports to meet the high bandwidth requirements of surveillance networks.
Adopts a shared buffer architecture, which multiplies the available buffer space for each port and significantly improves forwarding performance under burst heavy traffic.
PoE models support enhanced Ethernet power supply (PoE+), delivering up to 30W output per port to power high‑power surveillance cameras.
As unmanaged security switches, the MS4000 series feature simple operation and plug‑and‑play deployment, ideal for high‑performance surveillance networks with basic network policies.
Built with professional lightning protection circuits, providing 6KV common‑mode surge protection.

Supports DIP switch configuration for simplified network deployment and high‑performance surveillance applications.

Specifications

Attribute	MS4008V2	MS4008V2-PWR	MS4010	MS4010-HPWR
Standards	Compliance with:IEEE 802.3 10BASE-T EthernetIEEE 802.3u 100BASE-TX Fast EthernetIEEE 802.3ab 1000BASE-T Gigabit EthernetANSI/IEEE 802.3 NWay auto-negotiationIEEE 802.3x flow control	Same as left	Same as left	Same as left
Fixed Ports	8 × 10/100/1000BASE-T Ethernet ports	8 × 10/100/1000BASE-T Ethernet ports	8 × 10/100/1000BASE-T Ethernet ports + 2 × 1000M SFP optical ports	8 × 10/100/1000BASE-T Ethernet ports + 2 × 1000M SFP optical ports
Switching Capacity	20Gbps	20Gbps	28Gbps	28Gbps
Forwarding Performance	16Mpps	16Mpps	20Mpps	20Mpps
Switching Mode	Store-and-Forward	Store-and-Forward	Store-and-Forward	Store-and-Forward
MAC Address Table	Supports automatic address learning and aging(Aging time: 300 seconds)	Supports automatic address learning and aging(Aging time: 300 seconds)	Supports automatic address learning and aging(Aging time: 300 seconds)	Supports automatic address learning and aging(Aging time: 300 seconds)
MAC Address Capacity	4K	4K	4K	4K
Dimensions (L×W×H)	155mm × 58mm × 27mm	294mm × 179mm × 44mm	230mm × 120mm × 43.6mm	294mm × 179mm × 44mm
Input Voltage	100–240V AC	100–240V AC	100–240V AC	100–240V AC
Lightning Protection	Common-mode protection: 6KV	Common-mode protection: 6KV	Common-mode protection: 6KV	Common-mode protection: 6KV
Full-load Power Consumption	≤4.6W	≤148W (PoE: 125W)	≤5.9W	≤150W (PoE: 125W)
Operating Temperature	0℃～40℃	0℃～40℃	0℃～40℃	0℃～40℃
Operating Humidity	5%～95%, non-condensing	5%～95%, non-condensing	5%～95%, non-condensing	5%～95%, non-condensing
