| Brand Name: | H3C |
| Model Number: | MS4000-EI Series |
| MOQ: | 1 |
| Price: | depending on order quantity and specific model |
| Payment Terms: | T/T |
| Supply Ability: | Up to 30 days |
One-click mode switching, supporting four working modes: Monitor Mode, Standard Switching, Aggregation Uplink, and Port Isolation.
Built-in lightweight web management for simpler configuration and maintenance.
(Web management is not supported on MS4028FX-EI and MS4028FX-HPWR-EI.)
Integrated security-grade high lightning protection circuits and built-in high-withstand-voltage professional power supply ensure stable operation in harsh environments.
Adopting an all-steel housing with full powder coating for superior corrosion resistance and eco-friendly performance.
Adopting a shared buffer architecture that multiplies the available buffer space for each port, greatly enhancing forwarding performance under burst heavy traffic.
Low power consumption, fanless and noise-free design.
Supports PoE+, with a maximum single-port power output of 30W.
Equipped with dedicated PoE chips and security-grade design to deliver stable and reliable performance for various surveillance scenarios.
Supports ultra-long-distance power supply, with a maximum transmission distance of up to 250 meters
(Note: Compatible terminal equipment is required).
| MS4000-EI Series Specifications | ||
| Attribute | MS4028FX-EI | MS4028FX-HPWR-EI |
|---|---|---|
| Dimensions (W*D*H) (mm) | 440mm * 174mm * 44mm | 440mm * 210mm * 44mm |
| Fixed Ports | 24 * 10/100/1000BASE-T ports (including 4 uplink ports),4 * 10G BASE-X SFP+ optical ports | 24 * 10/100/1000BASE-T ports (including 4 uplink ports),4 * 10G BASE-X SFP+ optical ports |
| Operation Modes | Monitor Mode, Standard Switching,Port Isolation, Aggregation Uplink | Monitor Mode, Standard Switching,Port Isolation, Aggregation Uplink |
| MAC Address Table | 16K | 16K |
| Port Switching Capacity | 128Gbps | 128Gbps |
| Forwarding Performance | 95.7Mpps | 95.7Mpps |
| Packet Buffer | 12Mbit | 12Mbit |
| Switching Mode | Store-and-Forward | Store-and-Forward |
| Simplified Web Management | Not Supported | Not Supported |
| PoE Power Supply | Not Supported | PoE+ SupportedMax Total Output: 370WMax Power Supply Distance: 250 meters(Note: Terminal adaptation required) |
| Power Supply | 100~240V AC | 100~240V AC |
| Heat Dissipation | Fan-cooled | Fan-cooled |
| Operating Temperature / Storage Temperature | 0℃～40℃ / -40℃～70℃ | 0℃～40℃ / -40℃～70℃ |
| Operating Humidity / Storage Humidity | 5%~95% (Non-condensing) | 5%~95% (Non-condensing) |
| Certifications | CQC Certification, Network Access License | CQC Certification, Network Access License |
| MTBF | ＞50000H | ＞50000H |
| Installation Method | Rack-mountable with mounting brackets | Rack-mountable with mounting brackets |
