H3C IE4120U series are unmanaged rack-mount industrial Ethernet switches launched by H3C

H3C IE4120U series are unmanaged rack-mount industrial Ethernet switches launched by H3C

Brand Name: H3C
Model Number: IE4120U-28TP
MOQ: 1
Price: depending on order quantity and specific model
Payment Terms: T/T
Supply Ability: Up to 15 days
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Switching Capacity:
128Gbps
Packet Forwarding Rate:
20Mpps
Dimensions:
44×260×440 Mm
Weight:
≤4.0kg
Power Input:
24~48VDC (18~55VDC)
Operating Temperature:
-40℃~75℃
Packaging Details:
See the hardware specification sheet for details based on the specific model
Supply Ability:
Up to 15 days
Product Description
Exquisite Craftsmanship, Rock-solid Reliability

The IE4120U series is a new generation of industrial switches developed in strict compliance with industrial specifications. Adopting a hardware platform built with industrial-grade components, the entire series delivers significantly higher component reliability than commercial-grade devices under the same operating conditions.

It features a fanless thermal circulation design. With multiple heat dissipation structures such as built-in heat sinks and thermal conductive glue, the switch maintains consistent and stable performance in harsh environments, supporting a wide operating temperature range from -40℃ to 75℃.

Equipped with four DIP switches on the device, it enables one-click management of multiple functions, including flow control, link aggregation, port isolation and loop detection.

It supports dual DC redundant power supply.

With excellent vibration and dust resistance, it meets the IP41 protection rating.

IE4120U-28TP Specifications

Item Parameter
Switching Capacity 128Gbps
Packet Forwarding Rate 20Mpps
Dimensions (W × D × H, mm) 44×260×440
Weight ≤4.0kg
Installation Method Rack mounting
Power Interface Phoenix terminal
DIP Switch 4-way DIP switch for quick configuration
DI/DO 1 × DI, 1 × DO
IP Protection Rating IP41
Service Ports 24 × 10/100BASE-T electrical ports,

4 × Combo ports (10/100/1000BASE-T electrical or 100/1000BASE-X SFP ports)
Power Input Dual redundant backup input: 24~48VDC (18~55VDC)
Static Power Consumption 14.0W
Full-load Power Consumption 20.0W
Heat Dissipation Fanless, natural heat dissipation
Operating Humidity 5%~95% (non-condensing)
Operating Temperature -40℃~75℃
Storage Temperature -40℃~85℃
