H3C WA6638 Indoor Wi-Fi 6 (802.11ax) Tri-Band 12-Stream Wireless Access Point with Built-in Antennas, 5.95Gbps High-Density Enterprise AP

Brand Name:	H3C
Model Number:	H3C WA6638
MOQ:	1
Price:	317$
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Document:

Dimensions:

239mm X 236mm X 52mm

PoE Standard:

802.3bt

Operating Temperature:

-10ºC To 55ºC

Transmit Power:

20dBm

Maximum Speed:

5.95Gbps

Packaging Details:

See the hardware specification sheet for details based on the specific model.

Product Description

H3C WA6638 Indoor Wi-Fi 6 (802.11ax) Tri-Band 12-Stream Wireless Access Point

Product Overview

The H3C WA6638 is a high-performance Wi-Fi 6 (802.11ax) wireless access point independently developed by H3C Technology Co., Ltd. Designed for high-density access and high-bandwidth scenarios including conferences, venues, and educational environments, this AP features H3C's advanced Comware network operating system platform enabling cloud-network-edge collaboration and innovative 4i technology for intelligent RF management, terminal management, service assurance, and network healing.

The device employs a tri-band twelve-stream design with a maximum aggregate access rate of 5.95Gbps, featuring 5GHz RF 1 (4 spatial streams, 2.4Gbps), 5GHz RF 2 (4 spatial streams, 2.4Gbps), and 2.4GHz band (4 spatial streams, 1.15Gbps).

Hardware Specifications

Properties	WA6638
Dimensions (LWH)	239mm * 236mm * 52mm
Fixed Interfaces	2 (1 * 100/1000M/2.5G/5G/10G electrical port, 1 * 10/100/1000M electrical port with PoE out for IoT expansion)
PoE	802.3bt power supply
Local Power Supply	54V DC local power supply supported
Console Port	1
USB Interface	1
Built-in Antenna	Built-in intelligent antenna system
Built-in IoT	BLE5.0/RFID
IoT Expansion	Supports chain IoT expansion for up to 5 full-standard IoT protocols (BLE, RFID, ZigBee)
Operating Frequency Band	802.11ax/ac/n/a: 5.725GHz-5.850GHz (China); 5.47GHz-5.725GHz; 5.15GHz-5.35GHz (China) 802.11ax/b/g/n: 2.4GHz-2.483GHz (China)
Transmit Power (Single)	20dBm
Adjustable Power Granularity	1dBm
Operating Temperature/Storage Temperature	-10ºC to 55ºC / -40ºC to 70ºC
Working Humidity/Storage Humidity	5% to 95% (non-condensing)
Power Consumption	≤29.35W (PSE cannot supply external power and USB function disabled) ≤47.25W (supports PSE external power supply and USB function)

Software Specifications

Properties	WA6638
Product Positioning	Indoor Deployment Type (5.1GHz 44 MIMO + 5.8GHz 44 MIMO + 2.4GHz 4*4 MIMO)
Working Mode	Fit (Managed by AC control) Cloud (Fat) - Managed by cloud or works independently Anchor AC - Fit AP can be managed as AC mode
Wi-Fi 6 (802.11ax) Support	Maximum speed: 2.4Gbps + 2.4Gbps + 1.15Gbps
Advanced Wi-Fi 6 Features	TWT, BSS Color, MU-MIMO, OFDMA, Only 11ax mode
Maximum Users per RF	512 (1536 maximum connected users)
Virtual APs	16 (Maximum 48 services for whole machine)
Security Features	WEP, TKIP, CCMP, WPA3, WAPI encryption 802.1x, MAC address, PSK, Portal authentication User isolation, Wireless EAD, wIDS/wIPS, 802.11w protection
Quality of Service	WMM, 802.1p priority mapping, QoS policy mapping, CAR, bandwidth management, load balancing
Management & Maintenance	AC centralized management, Cloud simplified management, Local web, Telnet, SSH, SNMP

*Note: "Supported" options in software specifications indicate support across all AP modes

Working Modes

Fit AP Mode: Managed by wireless controllers with Comware system for batch AP management.

Cloud AP Mode: Wireless networking without hardware AC, supporting PPSK, PSK, Portal, SMS, and WeChat authentication with cloud-based intelligent O&M.

Anchor Networking: Configuration and management without wireless controller devices.

Advanced Features

Intelligent O&M: Comprehensive data visibility, measurable performance metrics, and automatic optimization capabilities
Security Protection: Endpoint access security, Wireless Intrusion Prevention System (WIPS), wired access control
Air Interface Optimization: Radio Resource Optimization Policy (RROP) and Station Access Control Policy (SACP)
RF Resource Management: Automatic channel, bandwidth, and power adjustment for optimal performance
Application Assurance: Intelligent application identification and prioritization for critical services
Chain IoT Expansion: Support for multiple IoT protocols including RFID, ZigBee, and BLE
Roaming Optimization: 802.11r, 802.11k, and 802.11v support for seamless roaming
Only 11ax Access: Exclusive Wi-Fi 6 mode for maximum performance
Probe Scanning: Remote probe analysis and Doctor AP mode for troubleshooting
OFDMA Technology: Multi-user simultaneous transmission with reduced latency
Spatial Reuse Technology: BSS Coloring mechanism for improved channel utilization
TWT Technology: Terminal wake-up scheduling for energy efficiency
Flexible Forwarding: Local and policy-based forwarding options
IPv4/IPv6 Dual Protocol Stack: Native IPv6 support
EAD Wireless Access: End user admission domination for security policy enforcement
Chinese SSID Support: Up to 16 Chinese characters in SSID names
