H3C UAP673 802.11ax AX3000 Wi-Fi 6 Dual-Band Enterprise Ceiling Mount Wireless Access Point with Gigabit Port, PoE Powered for High-Density Indoor Network Coverage

H3C UAP673 802.11ax AX3000 Wi-Fi 6 Dual-Band Enterprise Ceiling Mount Wireless Access Point with Gigabit Port, PoE Powered for High-Density Indoor Network Coverage

Brand Name: H3C
Model Number: H3C UAP673
MOQ: 1
Price: 138$
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Document:
H3C UAP673.pdf
Dimensions:
190mm X 190mm X 30mm
Weight:
600g
Fixed Ports:
1 X 10/100/1000Mbps (PoE), 1 X 10/100/1000Mbps (LAN)
Transmit Power:
2.4G:23dBm; 5G:23dBm
Operating Temperature:
-10ºC To 55ºC
Packaging Details:
See the hardware specification sheet for details based on the specific model.
Highlight:

H3C UAP673 Wi-Fi 6 access point

,

AX3000 ceiling mount wireless AP

,

PoE powered enterprise access point

Product Description
H3C UAP673 802.11ax AX3000 Wi-Fi 6 Dual-Band Enterprise Ceiling Mount Wireless Access Point
H3C UAP673 is a Wi-Fi 6 (802.11ax) AP product independently developed by H3C Technology Co., Ltd., with three bands and six streams, and a maximum access rate of 5.375Gbps, meeting the wireless coverage needs of small, medium and micro enterprises and other indoor high-density scenarios.
Management Modes
  • Cloud management mode: Industry-leading capabilities including cloud remote management, monitoring, cloud authentication, cloud operation and maintenance, and network optimization
  • Local centralized management mode: Supports centralized management of cloud gateways such as MSG300, USG300, and UR series
Hardware Specifications
Dimensions (antenna interface and accessories not included) 190mm * 190mm * 30mm
Weight 600g
Shell color White
Fixed ports UpLink: 1 * 10/100/1000Mbps self-negotiating Ethernet port (PoE powered)
LAN: 1 * 10/100/1000Mbps self-negotiating Ethernet port
PoE Support 802.3af/at power
Power consumption ≤22.5W
Built-in antenna Built-in low-emission omnidirectional antenna (3dBi)
Transmit power (combined power) 2.4G: 23dBm; 5G: 23dBm; 5G: 23dBm
(Actual power adjusted according to national regulations)
Adjustable power granularity 10%
Operating frequency band 802.11ax/ac/n/a: 5.725GHz-5.850GHz (China); 5.47GHz-5.725GHz; 5.15GHz-5.35GHz (China)
802.11ax/b/g/n: 2.4GHz-2.483GHz (China)
Operating temperature/storage temperature -10ºC to 55ºC / -40ºC to 70ºC
Working humidity/storage humidity 5% to 95% (non-condensing) / 5% to 95% (non-condensing)
MTBF 2,151,007 hours
Software Specifications
802.11 protocols 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11n, 802.11ac, 802.11ax, 802.11k, 802.11v
WLAN security RSN, WPA3, WPA2, WPA, TKIP, CCMP, Open system, PSK, MAC address blacklist/whitelist
Wireless service SSID configuration, Hide SSID, Split RF bound wireless services, VLAN binding, User speed limit
Radio frequency management Power settings, Channel settings, DFS, RF switch, RF mode
Portal Authentication SMS authentication, one-click authentication, WeChat official account authentication, account authentication, membership authentication, No perceptual authentication, Portal escape
Key Features
OFDMA Technology: APs can subdivide wireless bandwidth and use different subcarriers to transmit data to multiple terminals simultaneously, reducing delay and improving user experience for low-latency applications.
Spatial Reuse Technology: Supports SR technology & BSS Coloring mechanism, improving channel multiplexing ability during high-density deployment and alleviating same-channel interference.
TWT Technology: Allows APs to uniformly schedule terminal wake-up and hibernation, reducing conflicts between terminals and achieving energy savings.
  • Plug and Play: Supports plug-and-play wireless services with cloud platform binding or local gateway management
  • Centralized Management: Can be centrally managed by MSG300/USG300/UR series multi-service gateways
  • Ad Hoc Network Features: Automatic device discovery, topology establishment, plug-and-play functionality with simplified configuration
  • High Reliability: Custom link detection, network analysis tools, and multiple fault recovery mechanisms
  • Performance: Maximum 384 wireless terminal connections, Single RF supports up to 8 SSIDs
