H3C UAP672X 802.11ax AX3000 Wi-Fi 6 Industrial Outdoor Wireless Access Point, IP67 Waterproof Dustproof, PoE Powered, Enterprise-Grade AP for Outdoor High-Density Wi-Fi Coverage

Brand Name:	H3C
Model Number:	H3C UAP672X
MOQ:	1
Price:	125$
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Document:

Dimensions:

101mm*110mm*250mm

Weight:

1.07KG

PoE Support:

802.3at Power Receiver

Power Consumption:

≤14.4W

Waterproof Rating:

Packaging Details:

See the hardware specification sheet for details based on the specific model.

Highlight:

H3C UAP672X outdoor Wi-Fi 6 access point

IP67 waterproof industrial wireless AP

PoE powered enterprise-grade outdoor AP

Product Description

H3C UAP672X 802.11ax AX3000 Wi-Fi 6 Industrial Outdoor Wireless Access Point

IP67 Waterproof Dustproof, PoE Powered, Enterprise-Grade AP for Outdoor High-Density Wi-Fi Coverage

Product Overview

H3C UAP672X is a Wi-Fi 6 (802.11ax) AP product independently developed by H3C Technology Co., Ltd., with dual-band quadruple streams and a maximum access rate of 2.975Gbps to meet the wireless coverage needs of small, medium and micro enterprises and other outdoor scenarios.

Management Modes

Cloud management mode: Industry-leading capabilities including cloud remote management, monitoring, cloud authentication, cloud operation and maintenance, and network optimization. This is the preferred management mode suitable for networking requirements of all sizes.
Local centralized management mode: Supports centralized management of cloud gateways such as MSG300, USG300, and UR series.

Hardware Specifications

Properties	UAP672X
Dimensions (antenna interface and accessories not included)	101mm * 110mm * 250mm
Weight	1.07KG
Shell color	White
Fixed port	Uplink: 1 * 10/100/1000Mbps Self-Negotiating Ethernet Uplink (PoE Powered)
PoE	Support 802.3at power receiver
The power consumption of the whole machine	≤14.4W
Built-in antenna	Built-in omnidirectional antenna (2.4G: 3dBi; 5G: 5dBi)
Transmit power	2.4G: 28 dBm; 5G: 28 dBm (combined power, actual power adjusted according to national regulations)
Adjustable power granularity	10%
Operating frequency band	802.11ax/ac/n/a: 5.725GHz-5.850GHz (China); 5.47GHz～5.725GHz; 5.15GHz~5.35GHz (China) 802.11ax/b/g/n: 2.4GHz-2.483GHz (China)
Operating temperature/storage temperature	-35ºC～65ºC / -40ºC～85ºC
Working humidity/storage humidity	0% ~100% (non-condensing) / 0% ~100% (non-condensing)
Waterproof rating	IP67
MTBF	2,171,266 hrs

Software Specifications

Characteristics	Description
802.11 protocol	802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11n, 802.11ac, 802.11ax, 802.11k, 802.11v
WLAN security	RSN, WPA3, WPA2, WPA, TKIP, CCMP, Open system, PSK, MAC address blacklist, MAC address whitelist
Wireless service	SSID configuration, Hide the SSID configuration, Split RF bound wireless services, The service template is bound to a VLAN, User speed limit
Radio frequency management	Power settings, Channel settings, DFS, RF switch, RF mode
Portal Authentication	SMS authentication, one-click authentication, WeChat official account authentication, account authentication, membership authentication, etc. (Networking must be coordinated with UR routing + cloud platform)

Key Features

Supporting OFDMA Technology: APs can subdivide wireless bandwidth and use different subcarriers to transmit data to multiple terminals simultaneously, reducing delay and improving user experience for low-latency applications.

Support Space Multiplexing Technology: Supports SR technology & BSS coloring mechanism, improving channel multiplexing ability during high-density deployment and enhancing spectrum resource utilization.

Support TWT Technology: Allows APs to uniformly schedule terminal wake-up and hibernation, reducing conflicts and unnecessary wake-ups for energy saving.

Plug and Play: Supports plug-and-play wireless services, providing wireless services when powered on with cloud platform binding or local gateway device management.

Ad Hoc Network Features: Based on native equipment intelligence, supporting automatic discovery between devices, automatic topology establishment, plug-and-play of new devices, and automatic synchronous configuration.

High Reliability: Supports custom link detection, multiple network analysis tools, and multiple fault recovery mechanisms to ensure stable network operation.

Performance Specifications

Maximum number of wireless terminal accesses: 256 (theoretical)
Single RF supports up to 8 SSIDs (including 1 managed Wi-Fi)
Support OFDMA technology
Support space multiplexing technology
Support TWT technology
