| Brand Name: | H3C |
| Model Number: | H3C UAP672-E |
| MOQ: | 1 |
| Price: | 71$ |
| Payment Terms: | T/T |
| Properties | UAP672-E |
|---|---|
| Dimensions (excluding antenna interface and accessories) | 220mm * 220mm * 35mm |
| Weight | 380g |
| Shell Color | White |
| Fixed Port | 1 * 100/1000/2500Mbps Self-Negotiating Ethernet Port Uplink (PoE Powered) |
| PoE | Supports 802.3at power receiver |
| Local Power Supply | Supported (power adapter not included) Power adapter input: 100-240V AC Power adapter output: 12V/1.5A Power adapter output ≥ 18W |
| Power Consumption | ≤13.5W |
| Built-in Antenna | Built-in low-emission omnidirectional antenna (2.4GHz: 3dBi, 5GHz: 4dBi) |
| Transmit Power | 2.4G: 27dBm; 5G: 27dBm (Combined power, actual power adjusted per national regulations) |
| Adjustable Power Granularity | 10% |
| Operating Frequency Band | 802.11ax/ac/n/a: 5.725GHz-5.850GHz (China); 5.47GHz-5.725GHz; 5.15GHz-5.35GHz (China) 802.11ax/b/g/n: 2.4GHz-2.483GHz (China) |
| Modulation Technology | OFDM, DSSS, MIMO-OFDM (11n/ac/ax) |
| Operating/Storage Temperature | -10ºC to 55ºC / -40ºC to 70ºC |
| Operating/Storage Humidity | 5% to 95% (non-condensing) |
| MTBF | 1,959,376 hours |
| Characteristics | Description |
|---|---|
| 802.11 Protocol Support | 802.11a/b/d/e/g/h/i/n/ac/ax/k/v |
| WLAN Security | RSN, WPA3, WPA2, WPA, TKIP, CCMP, Open system, PSK, MAC address blacklist/whitelist |
| Wireless Service | SSID configuration, Hide SSID, Split RF bound wireless services, VLAN binding, User speed limit |
| Radio Frequency Management | Power settings, Channel settings, DFS, RF switch, RF mode |
| Portal Authentication | SMS authentication, one-click authentication, WeChat official account authentication, account authentication, membership authentication, No perceptual authentication, Portal escape |
| Network Protocol | ARP, ICMP, NTP, DNS, TCP/UDP, DHCP, HTTP, HTTPS, IPv6, LLDP, 802.1q |
Supports OFDMA (Orthogonal Frequency Division Multiple Access) technology, allowing APs to subdivide wireless bandwidth and use different subcarriers to transmit data to multiple terminals simultaneously. This reduces delay caused by multi-user air interface resource conflicts and improves user experience for low-latency applications like voice and video.
Supports SR (Spatial Reuse) technology & BSS Coloring mechanism. Adjusts transmit power through link layer recognition packet color control terminal, improving channel multiplexing ability during high-density deployment and alleviating same-channel interference during multi-user use.
Supports TWT (Target Wake Times) technology, allowing APs to uniformly schedule terminal wake-up and hibernation. This reduces conflicts between terminals and minimizes unnecessary wake-ups, achieving energy efficiency.
The UAP672-E supports plug-and-play wireless services. It can provide wireless services when bound to the cloud platform or managed by local MSG300/USG300/UR series devices.
Can be centrally managed by MSG300/USG300/UR series multi-service gateways, supporting wireless service configuration, RF configuration, version updates, VLAN modification, and reset functions.
Based on native H3C equipment, featuring fast start, fast network distribution, fast tuning, fast troubleshooting, and fast cloud migration. Supports automatic device discovery, topology establishment, plug-and-play functionality, and automatic configuration synchronization.
Supports custom link detection and multiple network analysis tools, including various hang and dead detection and fault detection mechanisms. Features multiple fault recovery mechanisms to ensure stable network operation.
