| Brand Name: | H3C |
| Model Number: | H3C UAP672-S |
| MOQ: | 1 |
| Price: | 57$ |
| Payment Terms: | T/T |
Enterprise-grade 802.11ax dual-band wireless access point with high-density performance for office, school, hotel, and commercial environments.
The H3C UAP672-S is a Wi-Fi 6 (802.11ax) access point independently developed by H3C Technology Co., Ltd. With a maximum access rate of 2.975Gbps, dual-band five-stream architecture, and superior signal coverage quality, it meets the wireless coverage needs of small, medium, and micro enterprise indoor scenarios.
| Property | Specification |
|---|---|
| Dimensions (excluding antenna interface) | 220mm * 220mm * 35mm |
| Weight | 370g |
| Shell Color | White |
| Fixed Port | 1 * 10/100/1000Mbps Self-Negotiating Ethernet Uplink (PoE Powered) |
| PoE Support | 802.3at power receiver |
| Local Power Supply | Power adapter input: 100-240V AC; Output: 12V/1.5A (≥18W) |
| Power Consumption | ≤11.35W |
| Built-in Antenna | Low-emission omnidirectional antenna (2.4GHz: 3dBi, 5GHz: 4dBi) |
| Transmit Power | 2.4G: 27 dBm; 5G: 27 dBm |
| Operating Frequency Band | 802.11ax/ac/n/a: 5.725GHz-5.850GHz; 5.47GHz-5.725GHz; 5.15GHz-5.35GHz 802.11ax/b/g/n: 2.4GHz-2.483GHz |
| Operating Temperature | -10ºC to 55ºC |
| Storage Temperature | -40ºC to 70ºC |
| MTBF | 2,229,720 hours |
| Characteristic | Description |
|---|---|
| 802.11 Protocols | 802.11a/b/d/e/g/h/i/n/ac/ax/k/v |
| WLAN Security | RSN, WPA3, WPA2, WPA, TKIP, CCMP, Open system, PSK, MAC address blacklist/whitelist |
| Wireless Service | SSID configuration, hidden SSID, split RF bound services, VLAN binding, user speed limiting |
| RF Management | Power settings, channel settings, DFS, RF switch, RF mode |
| Portal Authentication | SMS, one-click, WeChat, account, membership authentication; No perceptual authentication; Portal escape |
| Performance Specifications | Max wireless terminals: 256; Single RF supports up to 8 SSIDs |
Supports Orthogonal Frequency Division Multiple Access, allowing APs to subdivide wireless bandwidth and use different subcarriers to transmit data to multiple terminals simultaneously, reducing delay and improving user experience for low-latency applications.
Supports SR technology & BSS Coloring mechanism, adjusting transmit power through link layer recognition to improve channel multiplexing ability during high-density deployment and alleviate same-channel interference.
Supports Target Wake Times technology, allowing APs to uniformly schedule terminal wake-up and hibernation, reducing conflicts between terminals and unnecessary wake-ups for energy saving.
